Lawn Tractors > Kubota > ZD221

Kubota ZD221

Kubota ZD221 lawn tractor photo
2008 -    Z200 Series
Zero-turn mower






Production:

Manufacturer:Kubota
Original price (USD)
   $11,659 ( 48 )
   $11,863 ( 54 )


Kubota ZD221 Engine:

   21HP Kubota 778cc 3-cyl diesel
full engine details ...


Capacity:

Fuel:6.1 gal [23.1 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:hydraulic wet disc


Dimensions & Tires:

Wheelbase:51 inches [129 cm]
Weight:124 to 1245 pounds
Front tire:13x5.0-6
Rear tire:23x10.5-12
full dimensions and tires ...


Kubota ZD221 attachments:

 48" mid-mount mower deck
 54" mid-mount mower deck
all ZD221 attachments ...


ZD221 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:differential power
Brakes:wet discs
Cab:Two-post foldable ROPS.


Electrical:

Ground:negative
Charging amps:14
Charging volts:14


Battery:

Number:1
Cold-cranking amps:475
Volts:12
