Lawn Tractors > Kubota > ZG222

Kubota ZG222

Kubota ZG222 lawn tractor photo
2008 -    Z200 Series
Zero-turn mower






Production:

Manufacturer:Kubota
Original price (USD)
   $8,160 (2015 48S )
   $8,568 ( 48P )


Kubota ZG222 Engine:

   22HP Kubota 768cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:7.1 gal [26.9 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:hydraulic wet disc


Dimensions & Tires:

Wheelbase:51 inches [129 cm]
Weight:1168 lbs [529 kg]
Front tire:13x5.0-6
Rear tire:23x10.5-12
full dimensions and tires ...


Kubota ZG222 attachments:

 48" mid-mount mower deck
all ZG222 attachments ...


ZG222 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:differential power
Brakes:wet discs
Cab:Two-post foldable ROPS.


Electrical:

Ground:negative
Charging amps:13.4
Charging volts:12


Battery:

Number:1
Cold-cranking amps:300
Volts:12


Page information:

Last update:January 31, 2015
