Kubota Z724X


Kubota Z724X lawn tractor photo
2015 -
Z700 Series
Zero-turn mower
Production
ManufacturerKubota
TypeZero-turn mower
Original price$9,499 (2021 )
Kubota Z724X Engine
23.5HP Kawasaki 721cc 2-cyl gasoline
Fuel tank11.6 gal
43.9 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringpower
Brakesdrum discs
CabTwo-post foldable ROPS.
Photos
No photos of the Kubota Z724X are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric dry disc
Dimensions & Tires
Wheelbase50.9 inches
129 cm
Weight1163 to 1179 pounds
Front tire13x5.0-6
Rear tire24x9.5-12
Full dimensions and tires ...
Kubota Z724X attachments
48" mid-mount mower deck
54" mid-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps15
Battery CCA300
Battery volts12
References
Z724X reference literature
Z700 Series published in 2014, by Kubota
Z700 Series published in 2018, by Kubota
