Kubota Z125S

Kubota Z125S lawn tractor photo
2014 -    Z100 Series
Zero-turn mower






Production:

Manufacturer:Kubota
Original price (USD)
   $6,332 (2015 )


Kubota Z125S Engine:

   25HP Kohler 747cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:4.3 gal [16.3 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:electric dry disc


Dimensions & Tires:

Wheelbase:45.5 inches [115 cm]
Weight:771 lbs [349 kg]
Front tire:11x4-5
Rear tire:22x10-14
full dimensions and tires ...


Kubota Z125S attachments:

 54" mid-mount mower deck
all Z125S attachments ...


Z125S Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:differential power
Cab:Two-post fixed ROPS with suspended seat.


Electrical:

Ground:negative
Charging amps:15


Battery:

Number:1
Cold-cranking amps:300
Volts:12
