Lawn Tractors > Kubota > Z122E

Kubota Z122E

Kubota Z122E lawn tractor photo
2014 -    Z100 Series
Zero-turn mower






Production:

Manufacturer:Kubota
Original price (USD)
   $5,018 (2015 )


Kubota Z122E Engine:

   22HP Briggs & Stratton 724cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:4.3 gal [16.3 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:electric dry disc


Dimensions & Tires:

Wheelbase:45.5 inches [115 cm]
Weight:737 lbs [334 kg]
Front tire:11x4-5
Rear tire:22x10-14
full dimensions and tires ...


Kubota Z122E attachments:

 48" mid-mount mower deck
all Z122E attachments ...


Z122E Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:differential power
Cab:Two-post fixed ROPS.


Electrical:

Ground:negative
Charging amps:16


Battery:

Number:1
Cold-cranking amps:300
Volts:12
