Lawn Tractors > Snapper > UGT2260H

Snapper UGT2260H

Snapper UGT2260H lawn tractor photo
1998 - 1998
Garden tractor






Production:

Distributor:Snapper
Manufacturer:Power King
Factory:Beaver Dam, Wisconsin, USA


Snapper UGT2260H Engine:

   22HP Kohler 624cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:8.25 gal [31.2 L]


3-Point Hitch:

Rear Type:0*Optional


Power Take-off (PTO):

Rear PTO:independent*Optional
Rear RPM:2000
Front PTO:independent
Clutch:electric


Dimensions & Tires:

Wheelbase:57 inches [144 cm]
Weight:1200 lbs [544 kg]
Front tire:8-10
Rear tire:8.0-16
full dimensions and tires ...


Snapper UGT2260H attachments:

 48" mid-mount mower deck
 60" mid-mount mower deck
 snowblower
 blade
 front-end loader
all UGT2260H attachments ...


UGT2260H Serial Numbers:

Location:Left side of main tractor frame.

- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Final drives:spur bull gear
Steering:hydrostatic power
Brakes:mechanical band
Cab:Open operator station.


Electrical:

Ground:negative
Charging system:flywheel alternator
Charging amps:15


Battery:

Number:1
Volts:12
Amp-hours:45
