Snapper MGT2200H


Snapper MGT2200H lawn tractor photo
1997 - 1998
Garden tractor
Power King built
Production
Distributor:Snapper
Manufacturer:Power King
Type:Garden tractor
Factory:Beaver Dam, Wisconsin, USA
Snapper MGT2200H Engine
22HP Kohler 624cc 2-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Final drives:spur bull gear
Steering:hydrostatic power
Brakes:mechanical band
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Snapper MGT2200H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:8.25 gal
31.2 L
Tractor hitch
Rear Type:0*Optional
Power Take-off (PTO)
Rear PTO:independent*Optional
Rear RPM:2000
Front PTO:independent
Clutch:electric
Dimensions & Tires
Wheelbase:57 inches
144 cm
Weight:1200 lbs
544 kg
Front tire:8-10
Rear tire:8.0-16
Full dimensions and tires ...
Snapper MGT2200H attachments
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
MGT2200H Serial Numbers
Location:Left side of main tractor frame.
Electrical
Ground:negative
Charging system:flywheel alternator
Charging amps:15
Battery
Number:1
Volts:12
Amp-hours:45
