Power King 1618


Power King 1618 lawn tractor photo
1977 - 1983
1600 Series
Garden tractor
Production
ManufacturerPower King (a part of Engineering Products Company)
TypeGarden tractor
FactoryWaukesha, Wisconsin, USA
Power King 1618 Engine
18HP Kohler 588cc 1-cyl gasoline
Engine details ...
Power King 1618 Transmissions
3-speed gear
4-speed gear
9-speed gear
Transmission details ...
Mechanical
Chassis4x2 2WD
Final drivesbull gear
Steeringmanual
Brakesmechanical drum
CabOpen operator station. Vinyl weather cab optional.
Photos
No photos of the Power King 1618 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel3 gal
11.4 L
Hydraulic system5 gal
18.9 L
Hydraulics
Typeopen center
Capacity5 gal
18.9 L
Pressure1000 psi
69.0 bar
Pump flow1.7 gpm
6.4 lpm
Tractor hitch
Rear Type0 (optional)
Power Take-off (PTO)
Rear PTOindependent (optional)
Clutchelectro-magnetic
Rear RPM2000
Front PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase54.375 inches
138 cm
Weight976 to 993 pounds
Front tire4.00-12
Rear tire8.00-16
Full dimensions and tires ...
Power King 1618 attachments
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
1618 Serial Numbers
Location:Serial number decal on tractor dashboard and front of hood.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery volts12
References
1618 reference literature
Power King - One Tough Tractor published in 1980, by EPCO
