Power King 1217


Power King 1217 lawn tractor photo
1983 - 1987
1200 Series
Garden tractor
Series:1217
1218
Production
Manufacturer:Power King (a part of Engineering Products Company)
Type:Garden tractor
Factory:Waukesha, Wisconsin, USA
Power King 1217 Engine
17HP Kohler 691cc 2-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Brakes:disc
Cab:Open operator station.
Transmissions:8-speed gear
 hydrostatic
Transmission details ...
Capacity
Fuel:5 gal
18.9 L
Tractor hitch
Type:sleeve hitch (optional)
Power Take-off (PTO)
Rear PTO:independent (optional)
Rear RPM:2000
Front PTO:independent
Clutch:electro-magnetic
Dimensions & Tires
Wheelbase:48 inches
121 cm
Front tire:16x6.50-8
Rear tire:23x10.50-12
Full dimensions and tires ...
Power King 1217 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Ground:negative
Charging amps:15
Battery
Number:1
Volts:12
