Bolens 1669


Bolens 1669 lawn tractor photo
1990 - 1993
Medium Frame Series
Garden tractor
Production
Manufacturer:Bolens
Type:Garden tractor
Variants
1669L:hydraulic lift
Bolens 1669 Engine
16HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank:3.5 gal
13.2 L
Engine details ...
Mechanical
Steering:manual
Brakes:disc
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Tractor hitch
Type:sleeve hitch*Optional
Power Take-off (PTO)
Front PTO:independent
Clutch:electric
Dimensions & Tires
Wheelbase:49 inches
124 cm
Weight:785 lbs
356 kg
Front tire:16/6.50-8
Rear tire:23/8.50-12
Full dimensions and tires ...
Bolens 1669 attachments
42" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
