Bolens G12XL 1261


No photo available
1980 - 1981
Medium Frame Series
Garden tractor
Production
Manufacturer:Bolens
Type:Garden tractor
Bolens G12XL Engine
12HP Tecumseh 345cc 1-cyl gasoline
Engine details ...
Mechanical
Steering:manual
Brakes:disc
Cab:Open operator station.
Transmission:4-speed gear
Transmission details ...
Photos
No photos of the Bolens G12XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:1.6 gal
6.1 L
Tractor hitch
Type:sleeve hitch (optional)
Power Take-off (PTO)
Front PTO:independent
Clutch:electric
Dimensions & Tires
Wheelbase:49 inches
124 cm
Weight:703 lbs
318 kg
Front tire:16/6.50-8
Rear tire:23/8.50-12
Full dimensions and tires ...
Bolens G12XL attachments
42" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
