Bolens H16X1 1664


Bolens H16X1 1664 lawn tractor photo
1982 - 1983
Medium Frame Series
Garden tractor
H16XL
Series:H16X1 1664
Production
ManufacturerBolens
TypeGarden tractor
FactoryPort Washington, Wisconsin, USA
Bolens H16X1 Engine
16HP Tecumseh 453cc 1-cyl gasoline
Fuel tank1.6 gal
6.1 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
Brakesdisc
CabOpen operator station.
Photos
No photos of the Bolens H16X1 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase49 inches
124 cm
Weight700 lbs
317 kg
Front tire16x6.50-8
Rear tire23x8.50-12
Full dimensions and tires ...
Bolens H16X1 attachments
42" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
Battery AH53
References
H16X1 1664 reference literature
Bolens Tractors published in 1982
