Bolens 1476


Bolens 1476 lawn tractor photo
1970 - 1971
Large Frame Series
Garden tractor
Production
Manufacturer:Bolens
Type:Garden tractor
Bolens 1476 Engine
14HP Wisconsin 542cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Capacity
Tractor hitch
Rear Type:0*Optional
Dimensions & Tires
Wheelbase:49 inches
124 cm
Weight:860 lbs
390 kg
Front tire:5.70/5.00x8
Rear tire:27x8.50-15
Full dimensions and tires ...
Bolens 1476 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
