Kubota G1700
|
|
| Production | |
| Manufacturer | Kubota |
| Garden tractor | |
| Kubota G1700 Engine | |
| 11.2KW Kubota 656cc 3-cyl diesel | |
| Fuel tank | 5 gal 18.9 L |
 Engine details ... | |
| Kubota G1700 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Mechanical drum brakes | |
| Open operator station. |
| Photos | |
 | |
 Kubota G1700 photos... | |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 2000 |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 50 inches 127 cm |
| Weight | 706 lbs 320 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 23x10.50-12 |
 Full dimensions and tires ... | |
| Kubota G1700 attachments | |
| 121 cm mid-mount mower deck | |
| 137 cm mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| G1700 Serial Numbers | |
| Location: | Serial number decal on the left side of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Diesel Garden Tractor G1700H/G1800HS published in 1999, by Kubota |
