Ford LGT-120


Ford LGT-120 lawn tractor photo
1972 - 1983
Model year
LGT Series
Garden tractor
Jacobsen built
120
Series:LGT-100LGT-120LGT-125
Production
Distributor:Ford
Manufacturer:Jacobsen
Type:Garden tractor
Ford LGT-120 Engine
12HP Kohler 476cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Brakes:integral mechanical band
Cab:Open operator station. All-weather cab optional.
Transmission:4-speed
Transmission details ...
Capacity
Fuel:2 gal
7.6 L
Tractor hitch
Type:sleeve hitch*Optional
Power Take-off (PTO)
Front PTO:independent
Clutch:electric
Dimensions & Tires
Wheelbase:46 inches
116 cm
Weight:760 lbs
344 kg
Front tire:6.50-8
Rear tire:8.50-12
Full dimensions and tires ...
Ford LGT-120 attachments
42" mid-mount mower deck
50" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
Electrical
Ground:negative
Battery
Number:1
Volts:12
