Craftsman 107.25007


Craftsman 107.25007 lawn tractor photo
2012
CTX 9500 Series
Garden tractor
Simplicity built
107.28985
Series:107.25006107.25007
Production
DistributorCraftsman
ManufacturerSimplicity
TypeGarden tractor
Original price$6,500 (2012 )
Craftsman 107.25007 Engine
30HP Briggs & Stratton 810cc 2-cyl gasoline
Fuel tank3.6 gal
13.6 L
Engine details ...
Mechanical
Chassis4x2 2WD
Differential lockmechanical rear
Steeringpower
CabOpen operator station.
Photos
No photos of the Craftsman 107.25007 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Weight1173 lbs
532 kg
Front tire16x6.5-8
Rear tire24x12-12
Full dimensions and tires ...
Electrical
Groundnegative
Battery CCA500
Battery volts12
References
107.25007 reference literature
Discover the new CTX Tractor Series published in 2012, by Sears
