Cub Cadet HDS 2155
1996 - 1999 2000 Series Lawn tractor
Series map:
2150
2155
2160
15.0hp
15.0hp
16.0hp
Production Manufacturer Cub Cadet (a part of MTD)
Lawn tractor Original price $3,400 (1997 )
$3,300 (1998 )
$3,000 (1999 )
Mechanical Two-wheel drive Manual steering Mechanical drum brakes Open operator station.
Photos No photos of the Cub Cadet 2155 are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Power Take-off (PTO) Front PTO independent
Clutch electric
Front PTO Type pulley
2155 Serial Number Location Serial number plate on the left side of the 2155 frame, under the running boards.
Electrical Ground negative
Charging system flywheel alternator
Charging amps 15
Battery CCA 275
Battery volts 12
References Series 2000 Lawn Tractors published in 1998, by Cub Cadet Series 2000 Lawn Tractors published in 1999, by Cub Cadet Owner's Guide Series 2000 Tractors published by Cub Cadet Full Line published in 1996, by Cub Cadet 1998 Dealer Sales Manual published by Cub Cadet
Page information Copyright 2025 TractorData.com® Email me: Peter@TractorData.com TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. Peter Easterlund - owner/authorThis machine's data modified on September 16, 2025
©2000-2025 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
