Cub Cadet HDS 2155


Cub Cadet HDS 2155 lawn tractor photo
1996 - 1999
2000 Series
Lawn tractor
Series:2150HDS 21552160
Production
Manufacturer:Cub Cadet (a part of MTD)
Type:Lawn tractor
Variants
2150:gear
2155:hydrostatic
Cub Cadet 2155 Engine
15HP Kohler 426cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Brakes:internal expanding
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Cub Cadet 2155 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:3 gal
11.4 L
Power Take-off (PTO)
Front PTO:independent
Clutch:electric
Dimensions & Tires
Wheelbase:47 inches
119 cm
Weight:571 lbs
259 kg
Front tire:15x6-6
Rear tire:20x9-8
Full dimensions and tires ...
Cub Cadet 2155 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
2155 Serial Numbers
Location:Serial number plate on the left side of the 2155 frame, under the running boards.
Electrical
Ground:negative
Charging system:flywheel alternator
Charging amps:15
Battery
Number:1
Cold-cranking amps:275
Volts:12
