Cub Cadet 3186


Cub Cadet 3186 tractor photo
1999
3000 Series
Garden tractor
Series map:
3185
3186
3205
18.0hp
18.0hp
20.0hp
Production
ManufacturerCub Cadet (a part of MTD)
Garden tractor
Original price was $5,600 in 1999
Cub Cadet 3186 Engine
18HP Kohler 624cc 2-cyl gasoline
Fuel tank4.5 gal
17.0 L
Engine details ...
Mechanical
Two-wheel drive
Power steering
Disc brakes
Open operator station.
Photos
No photos of the Cub Cadet 3186 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type0 OptOptional
Power Take-off (PTO)
Front PTOindependent
Clutchelectro-pneumatic idler
Front PTO Typeshaft (SAE BB)
Dimensions & Tires
Wheelbase49.5 inches
125 cm
Weight720 lbs
326 kg
Front tire16x7.5-8
Rear tire24x10.5-12
Full dimensions and tires ...
Cub Cadet 3186 attachments
48" mid-mount mower deck
54" mid-mount mower deck
snowblower
blade
Attachment details ...
3186 Serial Numbers
Location:Serial number decal on the left side of the frame, above the front axle.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps16
Battery CCA435
Battery volts12
References
3186 references literature
Series 3000 Garden Tractors published in 1998, by Cub Cadet
3000 Series Service Manual (770-10227) published in 1999
