Craftsman 247.28885


Craftsman 247.28885 lawn tractor photo
2011 - 2013
LT 2000 Series
Lawn tractor
MTD built
Series map:
247.28884
247.28885
19.5hp
21.0hp
Production
DistributorCraftsman (a part of Sears)
ManufacturerMTD
Lawn tractor
Original price$1,300 (2012)
Variants
247.98886California emissions
Craftsman 247.28885 Engine
21HP Briggs & Stratton gasoline
Fuel tank1.5 gal
5.7 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Disc brakes
Open operator station. Medium-back seat with sliding adjustment.
Dimensions & Tires
Front tire15x6
Rear tire20x8x8
Full dimensions and tires ...
247.28885 Serial Numbers
247.28885 Serial Location
Craftsman 247.28885 serial number location
Serial number decal on the top of the fender deck, below the seat.
Electrical
Groundnegative
Battery volts12
References
247.28885 references literature
2011 Customer Buying Guide published by Sears
2012 Customer Buying Guide published by Sears
