Craftsman 917.27336


Craftsman 917.27336 lawn tractor photo
2004
LT 1000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.27336 Engine
16HP Briggs & Stratton 501cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station
Photos
No photos of the Craftsman 917.27336 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6.0-6
Rear tire18x8.5-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (headlights)
Battery CCA230
Battery volts12
Battery AH28
Battery GroupU1R
References
917.27336 references literature
2004 Riding Equipment published by Sears
