Lawn Tractors > Craftsman > 917.28934

Craftsman 917.28934

Craftsman 917.28934 lawn tractor photo
2009 - 2009   YT 3000 Series
Lawn tractor






Production:

Distributor:Sears
Manufacturer:Husqvarna
Original price (USD):$1,865 (2010)


Craftsman 917.28934 Engine:

   22HP Kohler 597cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:2.5 gal [9.5 L]


Dimensions & Tires:

Weight:514 lbs [233 kg]
Front tire:15x6x6
Rear tire:18x9.5x8
full dimensions and tires ...


Craftsman 917.28934 attachments:

 42" mid-mount mower deck
all 917.28934 attachments ...


917.28934 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:manual sector and pinion
Brakes:disc
Cab:Open operator station with adjustable seat and cup holder.


Electrical:

Ground:negative
Charging amps:15


Battery:

Number:1
Cold-cranking amps:230
Volts:12
Amp-hours:28
Group:U1R
