Craftsman 917.28928


Craftsman 917.28928 lawn tractor photo
2009
YT 4000 Series
Lawn tractor
Husqvarna built
Production
Distributor:Craftsman (a part of Sears)
Manufacturer:Husqvarna
Type:Lawn tractor
Original price:$1,990 (2010)
Craftsman 917.28928 Engine
24HP Briggs & Stratton 724cc 2-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Brakes:disc
Cab:Open operator station with adjustable seat and cup holder.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Craftsman 917.28928 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:3 gal
11.4 L
Dimensions & Tires
Weight:526 lbs
238 kg
Front tire:15x6x6
Rear tire:18x9.5x8
Full dimensions and tires ...
Electrical
Ground:negative
Charging amps:3 (battery)
 5 (headlights)
Battery
Number:1
Cold-cranking amps:230
Volts:12
Amp-hours:28
Group:U1R
