Lawn Tractors > Craftsman > 917.28947

Craftsman 917.28947

Craftsman 917.28947 lawn tractor photo
2009 - 2010   GT 5000 Series
Garden tractor






Production:

Distributor:Sears
Manufacturer:Husqvarna
Original price (USD):$3,480 (2010)


Variants:

28945:five-speed
28948:California emissions


Craftsman 917.28947 Engine:

   26HP Kohler 725cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:4 gal [15.1 L]


Rear Hitch:

Type:sleeve hitch (optional)


Dimensions & Tires:

Weight:644 lbs [292 kg]
Front tire:16x6.5x8
Rear tire:23x10.5x12
full dimensions and tires ...


Craftsman 917.28947 attachments:

 54" mid-mount mower deck
all 917.28947 attachments ...


917.28947 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:manual sector and pinion
Brakes:disc
Cab:Open operator station. Adjustable seat with arm rests and cup holder.


Electrical:

Ground:negative
Charging amps:15


Battery:

Number:1
Cold-cranking amps:230
Volts:12
Amp-hours:28
Group:U1R
