TractorData.com - information on all makes and models of tractors
Lawn Tractors > Craftsman > 917.28947
      -Brand search:


    Craftsman 917.28947

    Craftsman 917.28947 lawn tractor photo
    2009 - 2010   GT 5000 Series
    Garden tractor






    Production:

    Distributor:Sears
    Manufacturer:Husqvarna
    Original price (USD):$3,480 (2010)


    Variants:

    28945:five-speed
    28948:California emissions


    Craftsman 917.28947 Engine:

       Kohler 725cc 2-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:4 gal [15.1 L]


    Rear Hitch:

    Type:sleeve hitch (optional)


    Dimensions & Tires:

    Weight:644 lbs [292 kg]
    Front tire:16x6.5x8
    Rear tire:23x10.5x12
    full dimensions and tires ...


    Craftsman 917.28947 attachments:

     54" mid-mount mower deck
    all 917.28947 attachments ...


    917.28947 Serial Numbers:


    - Serial numbers unknown -



    Craftsman 917.28947 Power:

    Engine (gross):26 hp [19.4 kW]


    Mechanical:

    Chassis:4x2 2WD
    Steering:manual sector and pinion
    Brakes:disc
    Cab:Open operator station. Adjustable seat with arm rests and cup holder.


    Electrical:

    Ground:negative
    Charging amps:15


    Battery:

    Number:1
    Cold-cranking amps:230
    Volts:12
    Amp-hours:28
    Group:U1R


    Page information:

    Last update:March 25, 2013
    Copyright:Copyright 2013 TractorData LLC
    Contact:Peter@TractorData.com
    Copyright 2000-2013 - TractorData LLC. Notice: Every attempt is made to ensure the data listed is accurate. However, differences between sources, incomplete listings, errors, and data entry mistakes do occur. Consult official literature from the manufacturer before attempting any service or repair.
