Craftsman 247.28933


Craftsman 247.28933 lawn tractor photo
2009 - 2010
Revolution Series
Lawn tractor
MTD built
Production
DistributorCraftsman (a part of Sears)
ManufacturerMTD
Lawn tractor
Original price was $3,700 in 2010
Craftsman 247.28933 Engine
22HP Briggs & Stratton 656cc 2-cyl gasoline
Fuel tank2.8 gal
10.6 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Disc brakes
Open operator station.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Weight600 lbs
272 kg
Front tire15x5
Rear tire20x8
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
247.28933 references literature
2009 Riding Equipment published by Sears
