Lawn Tractors > Gravely > 408

Gravely 408

Gravely 408 lawn tractor photo
1970 - 1977   400 Series
Lawn tractor






Production:

Manufacturer:Gravely
Factory:Dunbar, West Virginia, USA
Total built:6,689 (1970-1975)
Original price (USD)
   $763 (1971 )


Gravely 408 Engine:

   8HP Kohler 304cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:1.125 gal [4.3 L]


Dimensions & Tires:

Weight:372 to 465 pounds
Front tire:13x5.00-6
Rear tire:18x8.50-8
full dimensions and tires ...


Gravely 408 attachments:

 34" mid-mount mower deck
 snowblower
 blade
all 408 attachments ...


408 Serial Numbers:

1970: 1003
1971: 1846
1972: 4022
1973: 4744
1975: 7225
1975: 200000
1976: 205039
1977: 259009
1978: 311672
Final: 372210

how to read serial numbers...



Links:

408 Group: Yahoo group dedicated to the Gravely 408


Mechanical:

Transmission:4-speed gear
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
