Ingersoll 3014


Ingersoll 3014 lawn tractor photo
1989 - 1997
3000 Series
Garden tractor
Series map:
3012
3014
3016
12.0hp
14.0hp
16.0hp
Production
ManufacturerIngersoll
Garden tractor
Built in Winneconne, Wisconsin, USA
Ingersoll 3014 Engines
14HP Kohler 512cc 1-cyl gasoline
14HP Briggs & Stratton 480cc 2-cyl gasoline
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Capacity
Fuel3 gal
11.4 L
Hydraulic system1.5 gal
5.7 L
Hydraulics
Typeopen center
Capacity1.5 gal
5.7 L
Pressure2000 psi (transmission)
137.9 bar
 575 psi (lift)
39.6 bar
Valves2
Pump flow8 gpm
30.3 lpm
Tractor hitch
Rear Type0 OptOptional
Typesleeve hitch OptOptional
Dimensions & Tires
Wheelbase46 inches
116 cm
Weight683 lbs
309 kg
Full dimensions and tires ...
Ingersoll 3014 attachments
42" mid-mount mower deck
44" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
3014 Serial Numbers
198914125700
199014126001
199114146700
199214168800
199314169220
199414180545
199514180873
199614190079
199717191383

FAQ: How to read a serial number table.
3014 Serial Location
Ingersoll 3014 serial number location
Serial number on the left side of the tractor frame, above the footrest.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery CCA230
Battery volts12
Battery AH32
References
3014 references literature
Compact Tractors 3010, 3012, 3014, 4014 (8-55970) published in 1989
Compact Tractors 3012, 3014, 3016, 3018, 3018PS, 4016, 4020, 4020PS (8-59130) published in 1993
