J.I. Case 110 XC

J.I. Case 110 XC lawn tractor photo
1981 - 1985   110XC Series
Model years
Lawn tractor
Series back:J.I. Case 108 XC






Production:

Manufacturer:J.I. Case
Factory:Winneconne, Wisconsin, USA
Original price (USD)
   $1,928 (1981 )


J.I. Case 110 XC Engine:

   10HP Briggs & Stratton 360cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:1 gal [3.8 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:mechanical idler pulley


Dimensions & Tires:

Wheelbase:42 inches [106 cm]
Weight:317 lbs [143 kg]
Front tire:5.00-6
Rear tire:8.50-8
full dimensions and tires ...


J.I. Case 110 XC attachments:

 34" mid-mount mower deck
 snowblower
 blade
all 110 XC attachments ...


110 XC Serial Numbers:

Location:Serial number plate on the dashboard of the Case 110 XC, below the steering column.
photo of 110 XC serial number


how to read serial numbers...



Mechanical:

Transmission:3-speed gear
Chassis:4x2 2WD
Steering:manual
Brakes:mechanical disc
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
Amp-hours:24
