Steiner 525
|
|
| Production | |
| Manufacturer | Steiner |
| Garden tractor | |
| Built in Johnson Creek, Wisconsin, USA | |
| Variants | |
| 75-70035 | 23.5HP Kubota diesel |
| 75-70040 | 28HP Kubota diesel |
| Steiner 525 Engines | |
| 28HP Kubota 1122cc 3-cyl diesel | |
| 23.5HP Kubota 898cc 3-cyl diesel | |
| Fuel tank | 7 gal 26.5 L |
 Engine details ... | |
| Steiner 525 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Four-wheel drive | |
| Articulated power steering | |
| Dry disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Steiner 525 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Type | Steiner Quick-Hitch |
| Dimensions & Tires | |
| Wheelbase | 49 inches 124 cm |
| Weight | 1520 lbs 689 kg |
| Front tire | 24x13.00-12 |
| Rear tire | 24x13.00-12 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging amps | 40 |
| Battery volts | 12 |
| Battery Group | 26 |
| References | |
 | |
| Uniquely engineered for unmatched versatility published in 1997, by Steiner |
