Wheel Horse 210-H


Wheel Horse 210-H lawn tractor photo
1990 - 1992
200 Series
Series:210-H212-H
Production
Manufacturer:Wheel Horse (a part of Toro)
Variants
210-H:hydrostatic
210-5:5-speed
Wheel Horse 210-H Engine
10HP Briggs & Stratton 399cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Wheel Horse 210-H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:1.5 gal
5.7 L
Dimensions & Tires
Wheelbase:44.5 inches
113 cm
Front tire:15x6.00-6
Rear tire:18x9.50-8
Full dimensions and tires ...
Wheel Horse 210-H attachments
30" mid-mount mower deck
36" mid-mount mower deck
38" mid-mount mower deck
Attachment details ...
210-H Serial Numbers
Location:Serial number located below the seat on the rear fender. Model numbers in parenthesis.
1990: (32-10BE01)
1991: 1000001 (32-10BE02)
1992: 2000001 (32-10BE03)

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:5
Battery
Number:1
Cold-cranking amps:160
Volts:12
