Wheel Horse 12-32XL


Wheel Horse 12-32XL lawn tractor photo
1996 - 2004
XL Series
Lawn tractor
Series:12-32XL16-44HXL
Production
Manufacturer:Wheel Horse (a part of Toro)
Type:Lawn tractor
Wheel Horse 12-32XL Engines
12HP Briggs & Stratton 465cc 1-cyl gasoline
12HP Briggs & Stratton 344cc 1-cyl gasoline
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.
Transmission:5-speed gear
Transmission details ...
Photos
No photos of the Wheel Horse 12-32XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:1.75 gal
6.6 L
Power Take-off (PTO)
Mid PTO:independent
Clutch:manual
Dimensions & Tires
Wheelbase:47 inches
119 cm
Weight:375 lbs
170 kg
Front tire:13x5.00-6
Rear tire:16x6.50-8
Full dimensions and tires ...
12-32XL Serial Numbers
Location:Serial number on top of tractor fender deck, below the seat.
1996: 6900001 (71188)
1997: 7900001 (71188/71189)
1998: 8900001 (71188/71189)
1999: 9900001 (71189)
2000: 200000001 (71199)
2001: 210000001 (71199)
2002: 220000001 (71199)
2003: 230000001 (71199)
2004: 240000001 (71199)

how to read serial numbers...

Electrical
Ground:negative
Battery
Number:1
Cold-cranking amps:160
Volts:12
