Lawn Tractors > Wheel Horse > B-111

Wheel Horse B-111

No photo available
1978 - 1979   B Series
Lawn tractor
Series back:Wheel Horse B-81






Production:

Manufacturer:Wheel Horse
Factory:South Bend, Indiana, USA


Wheel Horse B-111 Engine:

   11HP Briggs & Stratton 399cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:1.5 gal [5.7 L]


Dimensions & Tires:

Wheelbase:45.5 inches [115 cm]
Weight:405 lbs [183 kg]
Front tire:13x6.50-6
Rear tire:18x9.50-8
full dimensions and tires ...


B-111 Serial Numbers:

Location:Model codes shown.
1978: 82-11BP01 (3-speed)
1979: 92-11BP01 (3-speed)
1979: 92-11BF01 (6-speed)

how to read serial numbers...



Mechanical:

Transmission:3-speed
Transmission:6-speed gear
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.


Electrical:

Ground:negative
Charging amps:3


Battery:

Number:1
Volts:12
Amp-hours:24
