Kubota G1900


Kubota G1900 lawn tractor photo
1989 - 2000
G Series
Garden tractor
Series:G1800G1900G2000
G2160
Production
ManufacturerKubota
TypeGarden tractor
Variants
G1900two-wheel steer
G1900Sfour-wheel steer
Kubota G1900 Engine
18HP Kubota 719cc 3-cyl diesel
Fuel tank5 gal
18.9 L
Engine details ...
Mechanical
Chassis4x2 2WD
Brakesinternal expanding shoe
CabOpen operator station.
Tractor hitch
Rear Type0 OptOptional
Power Take-off (PTO)
Rear RPM2000
Dimensions & Tires
Wheelbase51 inches
129 cm
Weight706 to 750 pounds
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
Kubota G1900 attachments
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
blade
Attachment details ...
G1900 Serial Numbers
G1900 Serial Location
Kubota G1900 serial number location
Serial number plate on the right side of the Kubota G1900 tractor frame, above the front axle.
Electrical
Groundnegative
Charging amps12.5
Battery volts12
Battery AH45
