Lawn Tractors > Toro > Wheel Horse XL380

Toro Wheel Horse XL380



Toro Wheel Horse XL380 lawn tractor photo
2005 - 2010
XL Series
Lawn tractor
Series map:
XL320
XL380
XL440
13.0hp
16.0hp
17.0hp
Production
ManufacturerToro
Lawn tractor
Original price was $2,400 in 2004
Toro XL380 Engines
16HP Briggs & Stratton 465cc 1-cyl gasoline
16HP Briggs & Stratton 502cc 1-cyl gasoline
Fuel tank1.75 gal
6.6 L
Engine details ...
Toro XL380 Transmissions
5-speed gear
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Toro XL380 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase47 inches
119 cm
Weight486 lbs
220 kg
Front tire15x6.0
Rear tire18x9.5
Full dimensions and tires ...
Toro XL380 attachments
38" mid-mount mower deck
blade
Attachment details ...
XL380 Serial Numbers
2005250000001 (71427)
2005250000001 (71428)
2005250000001 (71246)
2006260000001 (71246)
2007270000001 (71246)
2008280000001 (71252)
2009280000001 (71252)
2010290000001 (71252)

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery CCA160
Battery volts12
