Lawn Tractors > Toro > Wheel Horse XL320

Toro Wheel Horse XL320



Toro Wheel Horse XL320 tractor photo
2005 - 2010
XL Series
Lawn tractor
Series map:
XL320
XL380
13.0hp
16.0hp
Production
ManufacturerToro
Lawn tractor
Toro XL320 Engine
13HP Briggs & Stratton 344cc 1-cyl gasoline
Fuel tank1.75 gal
6.6 L
Engine details ...
Toro XL320 Transmission
5-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Toro XL320 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchmanual
Dimensions & Tires
Wheelbase47 inches
119 cm
Weight425 lbs
192 kg
Front tire13x5.0
Rear tire16x6.5
Full dimensions and tires ...
Toro XL320 attachments
32" mid-mount mower deck
Attachment details ...
XL320 Serial Numbers
Location:Serial number plate below seat, on top of fender deck.
2005250000001 (71199)
2005250000001 (71209)
2006260000001 (71209)
2007270000001 (71209)
2008280000001 (71209)
2009290000001 (71257)
2010310000001 (71257)

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery volts12
