Lawn Tractors > Cub Cadet > 122

Cub Cadet 122

Cub Cadet 122 lawn tractor photo
1965 - 1967   1X2/1X3 Series
Garden tractor
Next model:Cub Cadet 124
Series next:Cub Cadet 123
Series back:Cub Cadet 102






Production:

Manufacturer:International Harvester
Factory:Louisville, Kentucky, USA


Cub Cadet 122 Engine:

   12HP Kohler 476cc 1-cyl gasoline
full engine details ...


Capacity:

Fuel:2 gal [7.6 L]


Power Take-off (PTO):

Rear PTO:transmission
Front PTO:independent
Clutch:mechanical


Dimensions & Tires:

Wheelbase:43 inches [109 cm]
Weight:800 lbs [362 kg]
Front tire:4.80x4.00-8
Rear tire:23x8.50-12
full dimensions and tires ...


Cub Cadet 122 attachments:

 38" mid-mount mower deck
 42" mid-mount mower deck
 48" mid-mount mower deck
 snowblower
 blade
all 122 attachments ...


122 Serial Numbers:

Location:Serial number plate on the rear of the tractor.
1965: 127161
1966: 137051
1967: 180268
Final: 218009

how to read serial numbers...



Mechanical:

Transmission:3-speed gear
Transmission:6-speed
Chassis:4x2 2WD
Steering:manual
Brakes:dry disc
Cab:Open operator station.


Electrical:

Ground:negative
Charging system:generator


Battery:

Number:1
Volts:12
