Massey Ferguson 2520H
|
|
| Production | |
| Distributor | Massey Ferguson |
| Manufacturer | Simplicity |
| Lawn tractor | |
| Variants | |
| Regent 20/38 | similar Simplicity model |
| Massey Ferguson 2520H Engine | |
| 20HP Briggs & Stratton 655cc 2-cyl gasoline | |
| Fuel tank | 3.5 gal 13.2 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Massey Ferguson 2520H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 50 inches 127 cm |
| Weight | 430 lbs 195 kg |
| Front tire | 15x6-6 |
| Rear tire | 20x8-8 |
 Full dimensions and tires ... | |
| Massey Ferguson 2520H attachments | |
| 38" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 9 |
| Battery CCA | 230 |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual Regent / 500 / 2500 Series (1730215) published in 2006 |
