| | Production: |
| Factory: | Horicon, Wisconsin, USA
|
| Manufacturer: | John Deere
|
| Total built: | -unknown- |
| | |
| Yanmar 3-cyl diesel |
| full engine details ... | | | Lawn Tractor Attachments: |
| Lawn mower: | 48 inches [121 cm]
54 inches [137 cm] (standard)
60 inches [152 cm]
|
| | Capacity: |
| Fuel: | 6.5 gal [24 L]
|
| | 3-Point Hitch: |
| Rear Hitch Category: | 0 (optional)
|
| Rear lift: | -unknown- |
| | |
| Rear PTO: | optional
|
| Rear speed (RPM): | 540
|
| Mid PTO: | hydraulic
|
| Mid speed (RPM): | 2000
|
| | Tires: |
| Lawn/turf front: | 16x6.50-8
16x7.50-8
18x8.50-8
|
| Lawn/turf rear: | 23x8.50-12
23x10.50-12
26x12.00-12
|
| | |
| | 1993: 010001
1994: 020001
1995: 030001
1996: 040001
1997: 050001
1998: 060001
1999: 070001
2000: 080001
2001: 090001
| | | |
| WeekendFreedomMachines.com: information, photos, allied equipment data, and an active John Deere lawn tractor forum |
|
| | Power: |
| Engine: | 22 hp [16.4 kW]
|
| | Mechanical: |
| Chassis: | 4x2 2WD
|
| Steering: | hydrostatic power
four-wheel steering optional
|
| Brakes: | wet disc
|
| Cab: | Open operator station.
|
|
|
| | Electrical: |
| Ground: | -unknown- |
| Alternator amps: | 20
|
| | Battery: |
| Number: | 1
|
| Cold-cranking amps: | 470
|
| Volts: | 12
|
| Amp-hours: | -unknown- |
