John Deere 185 Transmission


John Deere 185 lawn tractor photo
1986 - 1990
Late 100 Lawn Series
Lawn tractor
Series map:
180
185
17.0hp
17.0hp
Transmission
TransmissionSundstrand
Typebelt-driven hydrostatic
Gearsinfinite forward and reverse
Oil capacity0.75 qts
0.7 L
Eaton transmission with Peerless differential through 1987. Sundstrand transmission with Kanzaki differential beginning with the 1988 model year.
Speeds
With 18x8.50-8 rear tires.
185  belt-driven hydrostatic speeds
185 Transmission Controls
John Deere 185 transmission controls
1Forward/Reverse
2Throttle
3Brake
4Parking brake
