Caterpillar D4D
|
|
| Production | |
| Manufacturer | Caterpillar |
| Industrial Crawler tractor | |
| Caterpillar D4D Engine | |
| Caterpillar 5.7L 4-cyl diesel | |
| Fuel tank | 42 gal 159.0 L |
 Engine details ... | |
| Caterpillar D4D Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Caterpillar D4D Power | |
| Engine (net) | 65 hp 48.5 kW |
| Drawbar (claimed) | 52 hp 38.8 kW |
| Belt (claimed) | 59 hp 44.0 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | spur gear |
| Open operator station. | |
| Photos | |
| No photos of the Caterpillar D4D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tracks | |
| Weight | 13000 lbs 5896 kg |
| 13-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| D4D Track-type Tractor published in 1966, by Caterpillar |
