John Deere 344G

No photo available
1994 - 1997
Wheel Loader
ManufacturerJohn Deere
TypeWheel Loader
John Deere 344G Engine
John Deere 4.5L 4-cyl diesel
Fuel tank32 gal
121.1 L
Engine details ...
John Deere 344G Power
Engine (gross)90 hp
67.1 kW
Engine (net)85 hp
63.4 kW
Chassis4x4 articulated 4WD
Final drivesinboard planetary
Steeringarticulated power
Brakeshydraulic wet disc
CabFour-post ROPS canopy. Cab available with optional air-conditioning.
No photos of the John Deere 344G are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeopen center
Pressure3130 psi
215.8 bar
Pump flow29.3 gpm
110.9 lpm
Dimensions & Tires
Wheelbase100.4 inches
255 cm
Weight18255 lbs
8280 kg
Front tire15.5-25
Rear tire15.5-25
Full dimensions and tires ...
Charging systemalternator
Battery volts12
344G reference literature
Utility/Construction Purchasing Guide published in 1995, by John Deere
