Tractors > Allis Chalmers > D-17

Allis Chalmers D-17



Allis Chalmers D-17 industrial tractor photo
1960 - 1964
D Series
Industrial tractor
Series:D-15 ← D-17
Production
ManufacturerAllis Chalmers
TypeIndustrial tractor
FactoryWest Allis, Wisconsin, USA
Allis Chalmers D-17 Engines
Allis-Chalmers 3.7L 4-cyl gasoline
Allis Chalmers 4.3L 6-cyl diesel
Engine details ...
Allis Chalmers D-17 Transmissions
4-speed gear
8-speed two-speed power shift
4-speed shuttle
Transmission details ...
Allis Chalmers D-17 Power
Engine61 hp
45.5 kW
Belt (claimed)51.1 hp
38.1 kW
Plows5
Mechanical
Chassis4x2 2WD
Steeringmanual
 power OptOptional
CabOpen operator station.
Photos
No photos of the Allis Chalmers D-17 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel19 gal
71.9 L
Hydraulic system9 gal
34.1 L
Hydraulics
Typeopen center
Capacity9 gal
34.1 L
Power Take-off (PTO)
Rear PTOlive
Rear RPM540
Engine RPM540@1650
Dimensions & Tires
Gas Wheelbase93 inches
236 cm
Diesel Wheelbase95.75 inches
243 cm
Weight5765 lbs
2615 kg
Full dimensions and tires ...
Allis Chalmers D-17 attachments
front-end loader
backhoe
Attachment details ...
D-17 Serial Numbers
Location:Left-front of torque housing
Electrical
Groundpositive
References
D-17 reference literature
D-17 Series III Diesel Industrial Tractor published in 1963, by Allis Chalmers
Industrial Tractor Equipment published in 1962, by Allis Chalmers
