McCormick-Deering Industrial 20
|
|
| Production | |
| Manufacturer | McCormick-Deering (a part of International Harvester) |
| Type | Industrial tractor |
| Factory | Chicago, Illinois, USA |
| McCormick-Deering Industrial 20 Engine | |
| McCormick-Deering 4.7L 4-cyl gasoline | |
| Fuel tank | 14.5 gal 54.9 L |
 Engine details ... | |
| McCormick-Deering Industrial 20 Power | |
| Belt (claimed) | 20 hp 14.9 kW |
| Drawbar (tested) | 23.01 hp 17.2 kW |
| Belt (tested) | 29.87 hp 22.3 kW |
 Performance test details ... | |
| Mechanical | |
| Chassis | 4x2 2WD |
| Steering | manual |
| Brakes | manual internal expanding |
| Cab | Open operator station. |
| Photos | |
| No photos of the McCormick-Deering Industrial 20 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear RPM | 540 |
| Dimensions & Tires | |
| Wheelbase | 78 inches 198 cm |
| Weight | 4430 to 5300 pounds |
 Full dimensions and tires ... | |
| McCormick-Deering Industrial 20 attachments | |
| front-end loader | |
 Attachment details ... |
| Belt Pulley | |
| Diameter | 15.25 inches 38 cm |
| Width | 7 inches 17 cm |
| RPM | 645 |
| Speed | 2575 ft/min 784.86 meters/min |
| References | |
 | |
| McCormick-Deering Industrial Tractor and Operating Equipment published in 1923, by International Harvester |
