Massey Ferguson 50EX
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Industrial tractor | |
| Built in Manchester, England | |
| Massey Ferguson 50EX Engine | |
| Perkins 4.1L 4-cyl diesel | |
 Engine details ... |
| Massey Ferguson 50EX Transmission | |
| 4-speed power shuttle | |
 Transmission details ... |
| Massey Ferguson 50EX Power | |
| Engine | 73.5 hp 54.8 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | outboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post ROPS. Four-post ROPS canopy available. Cab available with heater. | |
| Capacity | |
| Fuel | 21.4 gal 81.0 L |
| Hydraulic system | 11.5 gal 43.5 L |
| Hydraulics | |
| Type | open center |
| Capacity | 11.5 gal 43.5 L |
| Pressure | 3000 psi (hitch) 206.8 bar |
| 2250 psi (loader) 155.1 bar | |
| Pump flow | 6.9 gpm (hitch) 26.1 lpm |
| 27.8 gpm (loader) 105.2 lpm | |
| Tractor hitch | |
| Rear lift | 4764 lbs 2160 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1893 |
| Dimensions & Tires | |
| 2WD Wheelbase | 81.5 inches 207 cm |
| 4WD Wheelbase | 80.7 inches 204 cm |
| Weight | 5508 to 6832 pounds |
| Front tire | 9.10-16 |
| Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| Massey Ferguson 50EX attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Batteries | 2 |
| Battery CCA | 330 |
| Battery volts | 12 |
| References | |
 | |
| MF50E/EX published in 1992, by Massey Ferguson |
