Tractors > John Deere > 450D

John Deere 450D



John Deere 450D industrial tractor photo
1982 - 1985
Bulldozer
Series map:
450D
72.0hp
Production
ManufacturerJohn Deere
Bulldozer
Built in Dubuque, Iowa, USA
John Deere 450D Engine
John Deere 3.6L 4-cyl diesel
Engine details ...
John Deere 450D Transmission
8-speed partial power shift
Transmission details ...
John Deere 450D Power
Engine (gross)72 hp
53.7 kW
Engine (net)67 hp
50.0 kW
Drawbar (claimed)50.1 hp
37.4 kW
Mechanical
Drivecrawler
Contracting band brakes
Four-post ROPS standard. Optional cab.
Photos
No photos of the John Deere 450D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel31 gal
117.3 L
Hydraulic system9.5 gal*Total system capacity with 6405 bulldozer.
36.0 L
Hydraulics
Typeopen center
Capacity9.5 gal*Total system capacity with 6405 bulldozer.
36.0 L
Pressure2250 psi
155.1 bar
Pump flow17 gpm
64.3 lpm
 23 gpm
87.1 lpm
Power Take-off (PTO)
Rear RPM1000 OptOptional
Dimensions & Tracks
Weight14640 lbs
6640 kg
16-inch tracks
Full dimensions and tracks ...
John Deere 450D attachments
blade
Attachment details ...
450D Serial Numbers
1982389172
1983700010
1984703985
1985711937

FAQ: How to read a serial number table.
Electrical
Charging systemalternator
Batteries1
 2 OptOptional
Battery volts12
References
450D references literature
450D/6405 Bulldozer published in 1983, by John Deere
