Ford 250C



Ford 250C industrial tractor photo
1989 - 1994
Industrial tractor
Series:250C → 260C
Production
ManufacturerFord
TypeIndustrial tractor
Ford 250C Engine
Ford 3.1L 3-cyl diesel
Engine details ...
Ford 250C Transmissions
8-speed constant mesh
8-speed torque converter
Transmission details ...
Ford 250C Power
Engine (gross)56 hp
41.8 kW
Engine (net)52 hp
38.8 kW
PTO (claimed)44 hp
32.8 kW
Mechanical
Chassis4x2 2WD
 4x4 MFWD 4WD
Differential lockmechanical rear
Steeringpower
Brakeswet disc
CabFour-post ROPS/FOPS.
Photos
No photos of the Ford 250C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel16 gal
60.6 L
Hydraulic system11 gal*Capacity with model 744 loader.
41.6 L
Steering2.4 qts
2.3 L
Hydraulics
Typeopen center
Capacity11 gal*Capacity with model 744 loader.
41.6 L
Pressure2200 psi
151.7 bar
Pump flow21.5 gpm (loader pump)
81.4 lpm
Steering flow5.9 gpm
22.3 lpm
Steering cap.2.4 qts
2.3 L
Tractor hitch
Rear TypeI/II
Controlposition and draft control
Rear lift3080 lbs
1397 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540 (1.375)
Engine RPM540@1800
Dimensions & Tires
Wheelbase81 inches
205 cm
Weight4948 to 7637 pounds
Front tire7.50-16
Rear tire16.9-24
Full dimensions and tires ...
Ford 250C attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA750
Battery volts12
Battery AH128
References
250C reference literature
Utility Tractors 250C - 260C Specifications published in 1989, by Ford
Construction Equipment Buyer's Guide published in 1989, by Ford
