Massey Ferguson 7S.190
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Row-Crop tractor | |
| Massey Ferguson 7S.190 Engine | |
| AGCO Power 6.6L 6-cyl diesel | |
| Fuel tank | 80.6 gal 305.1 L |
| Exhaust fluid (DEF) | 7.9 gal 29.9 L |
 Engine details ... | |
| Massey Ferguson 7S.190 Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Massey Ferguson 7S.190 Power | |
| Engine | 187.7 hp 140.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Massey Ferguson 7S.190 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Rear valves | up to 5 |
| Front valves | up to 2 |
| Pump flow | 29.1 gpm 110.1 lpm |
| 39.6 gpmOptOptional 149.9 lpm | |
| 50.2 gpmOptOptional 190.0 lpm | |
| Tractor hitch | |
| Rear Type | III |
| Rear lift | 21164 lbs 9599 kg |
| Front Hitch | III |
| Front lift | 7055 lbs 3200 kg |
| 8818 lbsOptOptional 3999 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1870 |
| 540E@1500 | |
| 1000@1900 | |
| 1000E@1530 | |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Engine RPM | 1000@1920 |
| Dimensions & Tires | |
| Wheelbase | 113.4 inches 288 cm |
| Weight | 13889 to 16535 pounds |
| Front tire | 480/70R28 |
| Rear tire | 580/70R38 |
 Full dimensions and tires ... | |
| References | |
 | |
| MF 7S published in 2021, by Massey Ferguson |
