Tractors > John Deere > 6R 175

John Deere 6R 175



John Deere 6R 175 tractor photo
2022 -
6R Series
Utility tractor
Series map:
6R 175
6R 195
173.0hp
191.8hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6R 175 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 6R 175 Transmissions
continuously-variable transmission
24-speed 4-speed power shift
24-speed 8-speed power shift
Transmission details ...
John Deere 6R 175 Power
Engine (gross)173 hp
129.0 kW
Engine (max)190.4 hp
142.0 kW
PTO (claimed)137 hp
102.2 kW
Mechanical
Four-wheel drive
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 6R 175 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center PFC
Pump flow41 gpm
155.2 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift9480 lbs
4300 kg
 10690 lbsOptOptional
4848 kg
Front HitchIIIN
Front lift7275 lbs
3299 kg
Dimensions & Tires
Wheelbase110.2 inches
279 cm
Weight18298 lbs
8299 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
6R 175 references literature
6R Utility Tractors published in 2021, by John Deere
