Belarus 1005
| | 1995 - 1996 |
| 1000 Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Belarus
|
| Type: | Row-Crop tractor
|
| Factory: | Minsk, Belarus
|
| Belarus 1005 Power |
| Engine: | 100 hp
74.6 kW
|
| PTO (claimed): | 92 hp
68.6 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Final drives: | spur gear
|
| Differential lock: | hydraulic
|
| Steering: | power
|
| Brakes: | mechanical disc
|
| Cab: | Cab standard.
|
| Transmission: | 18-speed
|
 Transmission details ... |
| Photos |
| No photos of the Belarus 1005 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 34.3 gal
129.8 L
|
| Hydraulic system: | 5.4 gal
20.4 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 5.4 gal
20.4 L
|
| Pressure: | 2250 psi
155.1 bar
|
| Valves: | 2 or 3
|
| Pump flow: | 11.9 gpm
45.0 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 4366 lbs
1980 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 540@1632
1000@1673
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 50
|
| Battery volts: | 12
|
