CaseIH Farmall 95A


No photo available
2020 -
Utility tractor
Series:Farmall 95AFarmall 105A
Production
Manufacturer:CaseIH
Type:Utility tractor
CaseIH Farmall 95A Power
Engine:97 hp
72.3 kW
PTO (claimed):78 hp
58.2 kW
CaseIH Farmall 95A Engine
FPT 3.4L 4-cyl diesel
ROPS Fuel tank:23.8 gal
90.1 L
Cab Fuel tank:29 gal
109.8 L
Exhaust fluid (DEF):2.9 gal
11.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:inboard planetary
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.
Transmissions:12-speed power shuttle
 20-speed creeper
Transmission details ...
Photos
No photos of the CaseIH Farmall 95A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Rear valves:2 or 3
Pump flow:16.9 gpm
64.0 lpm
 21.6 gpm
81.8 lpm *Optional
Tractor hitch
Rear Type:II/I
Control:top-link draft sensing
Rear lift (at ends):4409 lbs
1999 kg
Rear lift (at 24"/610mm):3200 lbs
1451 kg
 7716 lbs
3499 kg *Optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
 540/1000 (1.375)
Dimensions & Tires
2WD Wheelbase:91 inches
231 cm
4WD ROPS Wheelbase:84 inches
213 cm
4WD Cab Wheelbase:89 inches
226 cm
Weight:7304 to 8492 pounds
Front tire:10.00-16
2WD Rear tire:18.4-30
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:120
Battery volts:12
