CaseIH Farmall 35A Series II



CaseIH Farmall 35A Series II tractor photo
2017 -
Farmall A Series
Compact Utility tractor
Series map:
Farmall 35A
Farmall 40A
35.0hp
40.0hp
Production
ManufacturerCaseIH (a part of CNH)
Compact Utility tractor
Original price$20,207 (2021 gear )
$27,688 (2025 gear )
CaseIH Farmall 35A Engine
LS Mtron 1.9L 3-cyl diesel
Fuel tank7.4 gal
28.0 L
Engine details ...
CaseIH Farmall 35A Transmissions
12-speed mechanical shuttle
hydrostatic
Transmission details ...
CaseIH Farmall 35A Power
Engine35 hp
26.1 kW
Gear PTO (claimed)29.7 hp
22.1 kW
Hydro PTO (claimed)28 hp
20.9 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the CaseIH Farmall 35A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves1 OptOptional
Pump flow8.2 gpm
31.0 lpm
Gear Steering flow4.2 gpm
15.9 lpm
Hydro Steering flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)1808 lbs
820 kg
Rear lift (at 24"/610mm)1433 lbs
650 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540
Mid PTOindependent OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase67.5 inches
171 cm
Weight3067 lbs
1391 kg
Front tire7x14
Rear tire11.2x24
Full dimensions and tires ...
CaseIH Farmall 35A attachments
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging amps70
Battery volts12
References
Farmall 35A Series II references literature
Farmall Compact A published in 2019, by CaseIH
Farmall Compact published in 2019, by CaseIH
